SPARSH VP110
The Business IP Phone
Overview
SPARSH VP110 is a new breed of entry-level SIP phone that redefines the desktop telephony experience and quality of business communications. It provides features and functions normally available in high-end phones such as large graphical LCD, 5-line display, context sensitive keys, full-duplex speakerphone, integrated PoE, auto provisioning and broad array of call management features. Perfect fit for everyday users with basic communication needs, SPARSH VP110 finds its applications in call centers, enterprises, small businesses and branch offices.
Specifications
|
Audio Features |
Full-duplex Hands-free Speakerphone with AEC Codecs: G.711(A/μ), G.722, G.723, G.729, G.726, iLBC DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO VAD, CNG, AEC, PLC, AJB, AGC |
|
Phone Book |
Local Phonebook up to 1000 entries Black List XML Remote Phonebook Intelligent Search Method Phonebook Search/Import/Export Call History: Dialed/Received/Missed/Forwarded |
|
Phone Features |
1 VoIP Account Call Hold, Mute, DND One-touch Speed Dial, Hotline Redial, Call Return, Auto Answer Call Forward, Call Waiting, Call Transfer Local 3-way Conferencing Direct IP Call without SIP Proxy Ringtone Selection/Import/Delete Keypad Lock, Emergency Call Set Date & Time Manually or Automatically Dial Plan, XML Browser, Action URL/URI Instant Messaging (Web UI and Phone) |
|
Call Management |
Anonymous Call (CLIR) Anonymous Call Rejection Message Waiting Indicator (MWI) Voicemail, Call Pickup Intercom, Paging, Music on Hold Call Completion, Hot-desking Dial out Number from Web UI |
|
Display |
132x64-pixel Graphical LCD LED for Incoming/Ongoing Call, MWI, Mute, Hold Intuitive User Interface with Icons and Soft keys Multiple Languages Caller ID with Name, Number |
|
Networking and Security |
SIP v1 (RFC2543), v2 (RFC3261) IPv6 NAT Transverse: STUN Mode Proxy Mode and Peer-to-Peer SIP Link Mode IP Assignment: Static/DHCP/PPPoE HTTP/HTTPS Web Server Time and Date Synchronization using SNTP UDP/TCP/DNS-SRV (RFC 3263) QoS: 802.1p/Q Tagging (VLAN), Layer 3 ToS, DSCP SRTP for Voice Transport Layer Security (TLS) HTTPS Certificate Manager AES Encryption for Configuration File Digest Authentication using MD5/MD5-sess IEEE802.1X SNMP v1/v2 |
|
Management |
Configuration: Browser/Phone/Auto Provision Auto Provision via FTP/TFTP/HTTP/HTTPS for Mass Deploy Factory Reset Soft Reboot Package Tracing System Log |
|
Physical Features |
2 x 10/100 Mbps LAN & PC Ports 29 keys including 4 Soft Keys 1 x RJ9 Handset Port 1 x RJ9 Headset Port Dimension (W x D x H): 185 x 188 x 143 mm |
Mechanical:
|
Packaging |
10 Qty/CTN |
|
Net Weight |
9.8 Kg |
|
Gross Weight |
10.8 Kg |
|
Gift Box |
215 x 200 x 121 mm |
|
Installation |
Wall Mount, Table-top |
|
Color: |
Gray |
Environmental:
|
Operating Temperature |
-10° C to 50°C (14° F to 122° F) |
|
Operating Humidity |
10 - 95% (Non-Condensing) |
|
Certifications |
CE, FCC-15 (Class B), RoHS |
