Technical Specifications

Technology

SLT (Analog Station)

CO (Central Office)/Two-Wire Trunk (TWT)

Power Supply

Mechanical

Environment

Range of SOHO PBX

Key Features

3-Participants Conference

VISIONPRO allows 3 people to converse in a single conference. A useful feature to consult or conduct a meeting with colleague over the phone, saving time and increase productivity.

Abbreviated Dialing

Matrix VISIONPRO stores frequently used numbers in the system memory (90 numbers). The users can dial out this number with its access code and index number.

Allowed and denied list

VISIONPRO prevents misuse of long distance and international dialing to control telephone cost. A comprehensive list of numbers can be included in the Allowed and Denied Lists. However, it allows dialing of a few numbers and restricts dialing of other numbers in the same area. For example: An extension can dial only '22-628-5738' but not any other number starting with '22'.

Alternate Number Dialing

Whenever redial or auto redial is used, the VISIONPRO dials out the next alternative number instead of the same number that is found engaged.

Auto Redial-Multiple Numbers

VISIONPRO redials a busy number till it gets through. The user is free to concentrate on his work while the system is trying a busy number. The extension gets a ring and the number connected to is displayed on the telephone when the call goes through. Each user can submit up to 3 numbers for auto redial.

Auto Attendant

The caller can directly reach an extension without the help of an operator. VISIONPRO has a built-in Auto-Attendant playing different message like welcome message, Dial-by-Name, Dial Extension, Busy, No-Reply, Transferring to Operator, etc. These messages can be recorded in a 4-minute voice module. It also allows the caller to a desired extension by dialing the name of the extension user.

Auto Call Back

Station user need not keep dialing busy station repeatedly. By this feature, VISIONPRO allows you to get connected as it gets free.

Caller Line Identification (DTMF & FSK)

This function identifies the phone number of the caller and displays it on the telephone. The CLI is displayed for both internal and external caller. Even in case of a call being transferred from one extension to another, the system informs about both the numbers.

Class of Service

VISIONPRO allows the supervisor to decide upon the access rights to features for each extension, thus allowing you to configure the system as per your requirements. For example, extension 201 (middle management executive) can have features like conference, Auto Redial, Abbreviated Dialing, Alarms, Do-not-Disturb and call transfer only; whereas Extension 501 (pantry) can be configured to dial intercom numbers only.

CLI based External Call Forwarding (ECF)

The system offers the facility of forwarding selective incoming calls to a desired external number. Selective call forwarding is possible by defining a string of numbers. For example, the system could be programmed such that all numbers with a prefix "22" are forwarded to the residence number, however number can be forwarded.

CLI based Routing

The system can be programmed such that particular numbers land at specified extensions directly without the assistance of an operator, thus saving time and cost for the callers.

Conference

It allows 3 people to converse in a single conference. Such dual 3-party conference is possible. A useful feature to consult or conduct a meeting with colleague over the phone, saving time and increase productivity.

Direct Inward Dialing (DID)

Frequent callers can reach desired station by dialing the station number. In this feature system will perform the task of an operator.

Direct Outward System Access (DOSA)

It allows a user to access the system′s resources from a remote location. Thus a user can make calls to any external number; using the trunk lines connected to the system from a remote location. The Feature has password protected access to ensure security.

Flexible Numbering

This function allows you to define the extension numbers as per your convenience. You can have 1, 2, 3 or 4 digit extension numbers. Not only that but within the same system, you can also have combinations of 1, 2, 3 and 4 digit extension numbers.

Hotline

VISIONPRO offers great use to those stations which make more trunk calls than internal calls. As soon as the station user picks up the receiver, he/she gets access to the desired trunk line, saving time and effort. This function also offers a variant whereby a specified telephone number may be dialed as soon as the handset is picked up, or after a pre-defined delay.

Least Cost Routing

VISIONPRO can be programmed to ensure least cost incurred for each call by choosing specific trunk lines based on their prevailing tariffs. This function has a great utility now with the presence of multiple basic service providers offering various tariff plans for diverse destinations during different timings.

Live Call Supervision

VISIONPRO allows you to define feature access code as per your convenience. It offers the users great convenience as they do not have to remember the new codes in case of change of the system.

Programmable Access Codes

VISIONPRO allows you to define feature access code as per your convenience. It offers the users great convenience as they do not have to remember the new codes in case of change of the system.

Remote Programming

Matrix VISIONPRO can be engineered for change in its programming from a remote location also. This does not even require a PC or any other specialized device at the site.

Features List
